Description
Features
- Quality waterproof anti-metal sticker
- Flexible, read range 1.1 in (3 cm) to 3.2 ft (1 m)
- Wide frequency 840 MHz to 960 MHz
- Stable performance, free SDK & test tag samples
Technical Specifications
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Frequency | 860 MHz to 960 MHz |
| Chip | Impinj M4QT or MonzaR6 or R6P |
| Memory | M4QT: EPC is 128bits, User memory of 512bits |
| Working Method | Read-write |
| Data Retention | 50 Years |
| Main Material | PET |
| Color | White |
| Installation Method | 3M 300LSE Sticker (Or other customized) |
| Packing | Antistatic bags and carton packing |
| Drop Test | Passed 200 times drop tested from 3.2 ft (1 m) |
| Alcohol Test | Passed 95 % alcohol test |
| RoHS | Passed, material passed SGS |
| Protection Level | IP65 |
| Fixed Reader (Tag On Metal) |
Above 9.8 ft (3 m) (4W EIRP, Alien9900) |
| Hand Reader (Tag On Metal) |
Above 6.5 ft (2 m) (Alien9011) |
| Polarization Mode | Linear polarization |
| Radio Frequency Performance Consistency Detection | 100 % test and pass (using Voyantic Tagform tester in Finland, Europe) |
| High and Low Temperature Alternating Test | Passed the seven cycles of high and low temperature alternation from -13 °F to 158 °F (-25 ℃ to + 70 ℃) with two consecutive days. |
| Working Temperature | -13 °F to 158 °F (-25 ℃ to +70 ℃) |
| Storage Temperature | -13 °F to 158 °F (-25 ℃ to +70 ℃) |
| Storage Humidity | 5 % to 95 % |
| Size | 2.3 in x 0.9 in x 0.07 in (60 mm x 25 mm x 1.8 mm) (0.01 in (+-0.3 mm)) or Customized |
| Weight | 0.07 oz (2.0 g) |
