Description
Features
- Adopt micro-UHF antenna.
- Completely independent intellectual property design
- Working frequency: 840 MHz to 960 MHz (customized)
- Support protocol: EPC C1 GEN2/ ISO 18000-6C
- USB power supply for mobile phones
- Working current is about 200 mA
- LED light, red indicates card reading status
- Maximum reading distance is about 3.93 in (100 mm)
- Provide Android mobile DEMO and development
Technical Specifications
| Frequency | 865 MHz to 868 MHz (EU) 902 MHz to 928 MHz (US) |
| Protocol | ISO18000 – 6C (EPC GEN2) |
| Interface | USB 2.0 (Free drive) |
| RF Power | 18 dBm to 26 dBm (adjustable) |
| Tow Modes | Write tag mode (read and write) Keyboard input mode (only read) |
| Read Speed | Single card average reading < 6 ms per 32 bits (set by software) |
| Read Distance | 3.93 in (100 mm) (depends on tag) |
| Write Distance | 1.97 in (50 mm) (depends on tag) |
| Read Tip | Buzzer and led |
| Built-In Antenna | 1 dBi |
| Power Supply | Mini USB |
| Way of Working | FHSS |
| Working Temp | 14 °F to + 131 °F (-10 °C to + 55 °C) |
| Size | 3.93 in x 2.75 in x 0.39 in (100 mm x 70 mm x 10 mm) |
| Weight | 3.5 oz (100 g) |
