Description
Features
- Based on the New Generation Impinj E710 reader chip
- Support EPC global Gen2 (ISO 18000-6C)
- 33 dBm RF power output
- High performance of anti-collision recognition algorithm
- Real-time monitoring of on-board temperature
- Metal housing, helpful in heat dissipation
Technical Specifications
| Air Protocols | EPC Class 1Gen 2(ISO 18000-6C) |
| Frequency | 860 MHz to 960 MHz |
| Chipset | lmpinj E710 |
| Sensitivity | -86 dBm |
| Antenna Port | Four 50 Ω SMA Connectors |
| Output Power | 5 dBm to 30 or 33 dBm (± 1 dBm) adjustable |
| Connector Interface | 15 pin MOLEX53261-1571 Connector (Power supply, Communication, GPIO) |
| Tag RSS | Support |
| Antenna Detector | Support |
| Temperature Detector | Support |
| Host API | C, C#/.NET, Java |
| Max Read Rate | 900 tags per second |
| Max 1ag Need Distance | 39.37 ft (≥ 12 m) with 8 dBi antenna |
| Dimensions | 2.94 in x 1.90 in x 0.34 in (7.48 cm × 4.85 cm × 0.8 cm) |
