Description
Technical Specifications
| Standard | ISO18000-6B/ISO18000-6C/EPC Class1G2 |
| Working Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHZ |
| Interface | Wiegand263442, RS485, RS232 (TCP/IP, WIFI and GPRS is customizable) |
| Power Supply | DC-7.5 to 12 V, 3 A |
| Development Kit | Provide SDK development kit, and C#, C++, Java routines |
| Antenna Power | 1 W (adjustable by software) |
| Input/Output Interface | 1 way trigger input or 2-way relay output (customized) |
| Ani-Thunder | 6000 V |
| Antenna | 12 dBi polarization |
| Reading Range | 65.61 ft to 82 ft (20 m to 25 m) |
| Operating Temperature | -49 °F to 149 °F (-45 ℃ to 65 ℃) |
| Size | 17.71 in x 17,71 in x 1.96 in (450 mm x 450 mm x 50 mm) |
| Weight | 11 lb (5 kg) |
