Description
Features
- Operation Systems & Multi-Function
- Ultra-low power design
- Support interactive and trigger-activating work mode
- RF output power 0 dBm to 26 dBm (adjustable)
- Supported Tag RSSI
- Multiple Tag Reading anti-collision > 50 pcs per s
- Multiple tag inventory speed> 50 pcs per s
- Support wireless: Blue-tooth 4.0.
- Interface: USB connectors
- Support USB charging & Built-in lithium battery
- SDK & Software can be provided
Technical Specifications
| Frequency | 865 MHz to 868 MHz (EU standard) 902 MHz to 928 MHz (US standard) |
| Protocol | ISO 18000-6C |
| Work Mode | Read and write |
| Interface | USB and Bluetooth |
| Reading Distance | 0 ft to 3.3 ft (0 m to 1 m) |
| Battery | 1 hr. to 2 hrs. continuous reading tag and over 1 day in standby |
| Performance | Multiple tag anti-collision > 50 pcs per s, multiple tag inventory speed > 50 pcs per s |
| Charging Voltage | 6 V |
| Charging Current | 500 mA |
| Standby Current | 14 mA (Max) 20 mA |
| Continuous RF Current | 100 mA (Max 200 mA) |
| Operating Temperature | 14 °F to +158 °F (-10 °C to +70 °C) |
| Storage Temperature | -4 °F to +185 °F (-20 °C to 85 °C) |
| Size | 4.3 in x 1.97 in x 0.23 in (110 mm x 50 mm x 5.8 mm) |
