| Frequency |
865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol |
EPC class1 Gen2 or ISO18000-6c |
| Type |
UHF RFID Reader |
| Card Type |
UHF Day |
| Interface |
Serial Port |
| Reading Distance |
> 32.8 ft (10 m) |
| Application |
Parking, Hospital, Library, Company, Bank, Store |
| Application Software Platform |
API (c++, c#) development kit (can be customized) |
| GPIO |
1 relay output, 1 trigger input |
| Power Supply |
220 V AC input, + 12 V or 2 A adapter DC output |
| Integrated Antenna |
12 dBi linear polarization |
| SDK |
C#, C++, Delphi, VB, Java |
| Communication |
Standard: RS232, RJ45, Wiegand; optional: 4G or WiFi Bluetooth or USB |
| Achievement |
30 dBm (adjustable in 1 dBm increments with the FDY demo software |
| Shell Material |
ABS + PC |
| Specification |
23.6 in x 23.6 in x 19.6 in (60 cm x 60 cm x 50 cm) |
| Front Antenna Housing Color |
Grey |
| Rear Antenna |
Aluminum Die Casting |
| Installation |
Holding Tree |
| Radio Frequency |
Independent R&D technology for the financial year |
| Read or Write Area |
Reading range 32.8 ft to 82.0 ft (10 m to 25 m), writing range > 29.5 ft (9 m) |
| Group Read Rate |
1 pc EPC Tag |
| Serial Rate |
9600 bps to 115200 bps |
| Price RJ45 |
10 Mbps |
| GPIO |
1 relay output, 1 trigger input |
| Reading The Ad |
Buzzer |
| Electricity Consumption |
1 W |
| Power Supply |
220 V AC input, +12 V or 2 A adapter DC output |
| Application |
Windows-based API development kit and application routine |
| SDK |
C#, C++, Delphi, VB, Java |
| Protection Level |
IEC IP65 |
| Light Protection |
Direct current |
| Standard |
Bracket, power supply |
| Humidity |
5 % to 95 % Relative Humidity, non-condensing |
| Operating Temperature |
-13 °F to 158 °F (﹣25 °C to﹢70 °C) |
| Storage Temperature |
-22 °F to 176 °F (﹣30 °C to﹢80 °C) |
| Size |
17.5 in X 17.5 in X 1.5 in (445 mm × 445 mm X 40 mm) |
| Weight |
12.1 lb (5.5 kg) |
