Description
Features
- The cover is made of ASA or ABS high temperature resistant material
- Outdoor waterproof design
- Beautiful appearance
- Good environmental adaptability
- Convenient and quick installation
Technical Specifications
| Frequency | US 902 MHz to 928 MHz EU 865 MHz to 868 MHz |
| Bandwidth | US 26 MHz EU 3 MHz |
| Gain | 12 dBi |
| E Plane | 40 ° |
| H Plane | 38 ° |
| VSWR | ≤ 1.3 |
| Front To Back Ratio | > 25 DB |
| Polarization Mode | Omni directional or linear polarization RFID antenna or Circular polarization |
| Maximum Power | 100 W |
| Impedance | 50 Ω |
| Connector | TNC N 50k |
| Cover Material | ABS |
| Size | 17.52 in x 17.52 in x 1.57 in (445 mm × 445 mm × 40 mm) |
| Weight | Gross 15.43 lb (7 kg) Net 9.92 lb (4.5 kg) |
