Description
Technical Specifications
| Protocol | ISO or IEC 18000-6c EPC Class1 Gen2 |
| Frequency | 860 MHz to 960 MHz |
| Chip | Alien Higgs 9 |
| Power Supply Mode | Passive |
| Material | Paper |
| Max Read Distance | > 19.6 ft (6 m) |
| Chip Memory | EPC 96 bits to 496 bits, User up to 688 bits |
| Operating Temperature | -40 °F to +158 °F (-40 °C to +70 °C) |
| Dimension | 1.73 in × 1.73 in × 0.53 in (44 mm x44 mm x13.5 mm) |
| Label Size | 3.77 in × 0.90 in, 3.93 in × 1.06 in, 3.93 In × 1.57 in (96 mm X 23 mm, 100 mm X 27 mm, 100 mm X 40 mm). |
| Antenna Size | 3.66 in × 0.75 in (93 mm X 19 mm) |
