Description
Features
- Heart rate monitor, Sonar ranging
- Body fat detection
- Interactive, Coaching and Display
- For gym equipment like treadmill, gym spinning, AI smart bike, self-powered exercise bike, rowing machine, cross trainer, chair bike, upright bike, air bike etc.
Technical Specifications
| Screen size | 10.1 in or 14 in or 15.6 in or 17.3 in or 18.5 in or 21.5 in or 23.8 in |
| Display resolution | 1024 x 600 or 1280 x 800 or 1920 x 1200 or 2 K or 4 K |
| Operating system | Android 12 or above or Linux or others |
| Type | Tablet PC |
| Drive Interface | USB Type C |
| Processor Manufacture | MediaTek or All winner or ROCKCHIP or Intel |
| Processor Type | Dual core or Quad core or Octa core |
| Network | Wi-Fi, GSM, 4 G, 3 G |
| Scenarios | Gym, Home, Office, Health Clubs, Rehabilitation clinics |
| Feature | Hard, SDK available |
| Charging interface | USB Type C POE DC POGO Pin Wireless |
| Private mold | Yes |
| Use | Home, Business, Entertainment, Mall |
| Processor main frequency | 1.5 GHz to 2.5 GHz |
| Touch screen type | Capacitive Screen |
| Mount way | Embedded |
| Functions | 3.0 UART GPIO RJ45 POE Wi-Fi Bluetooth 4G SIM LTE Z-wave |
| Power ports | DC in USB type C |
| Data ports options | SPI UART SPI TTL GPIO RS232 RS485 |
| Data transfer ports | USB type C HDMI RJ45 POE EDP MIPI VESA |
| Certification conformity | CE FCC KC SAA RCM ROHS REACH ect. |
| Factory certification | ISO900 ISO14001 |
| CPU | RK3288 quad-core Cortex-A17at1.8G GPU Mali |
| RAM | 2 GB or 4 GB or 6 GB or 8 GB |
| ROM | 16 GB or 32 GB or 64 GB or 128 GB |
| TP | Multipoint-Touch G + G |
| LCD | 11.6 in |
| Resolution | IPS 1920 x 1080 |
| Contrast | 800:1 |
| Brightness | 250 cd/m2 |
| Proportion of the screen | 16:9 |
| Wi-Fi | 802.11ac or b or g or n |
| BT | BT4.2 |
| Mobile network | Support for built-in 3 G or 4 G networks (none by default) |
| Ethernet | 10 M or 100 M or 1000 M Ethernet |
| USB interface | Support USB host x 2 |
| Headphone output | 11.48 ft (3.5 m) stereo headphone output |
| USB Type-C | Support USB upgrade and debugging |
| DC | DC power 12 V input |
| HDMI | Support HDMI output |
| TF Card | Maximum support 128 GB |
| RJ45 | Ethernet front-end ports |
| Speaker | Built-in 3 W or 8 Ω x 2 pcs |
| Headphone jack | 11.48 in (3.5 mm) stereo headphone output |
| Keys | Power button, volume plus, volume minus |
