Description
Technical Specifications
| Power Supply | External Power Adapter | |
| Input | AC 100V to 240V, 50 Hz to 60 Hz | |
| Output | 24 V DC, 3 A | |
| Memory | SDRAM | 8 MB |
| FLASH | 8 MB | |
| Interface | Standard | USB (2.0 Full-Speed) |
| Optional | Serial (RS-232, DB25) Parallel Centronics (IEEE-1284) Wi-Fi (802.11b perg) Bluetooth: BT 3.0 or 4.0+EDR, SPP |
|
| Software | Driver (Windows 32bit or 64bit), Bartender, SDK System, Setup Tool | |
|
Safety Standard Reliability
|
Safety | UL, CE, FCC, CCC, EMC |
| EMC | Class B | |
| Certificate | CCC, CE, FCC, UL, Energy star | |
| TPH Lifetime | 93.2 mi (150 km) | |
|
Physical Specs
|
Dimensions | 9.0 in × 11.4 in × 6.92 in (230 mm × 290 mm × 176 mm) |
| Casing Color | Black | |
| Weight | Approx 6.6 lb (3 kg) | |
| Operating Condition | 41 °F to 104 °F (5 ℃ to 40 ℃) or 20 % to 95 % RH (non-condensing) | |
| Storage Condition | -4 °F to 140 °F ( -20 ℃ to 60 ℃) or ≤ 95% RH (non-condensing) | |
| Weight | Approx 6.6 lb (3 kg) | |
