Description
Overview
Amuse Tech Solutions RFID UHF Integrated Reader is an integrated RFID reader with a new and innovative antenna that is compatible with IS018000 and EPC Class 1 Gen2 of RFID tags. solves many problems associated with successful remote identification, rapid identification of moving objects, and identification with multiple cards. The design of this RFID reader includes Weigand; RS485; RS232; WIFI (optional) and TCP/IP RJ45 (optional) output interfaces.
Technical Specifications
| Support Protocol | ISO18000-6C (EPC CLASS1 GEN2) |
| Working Frequency | 902 MHz to 928 MHz (USA) or 865 MHz to 868 MHZ (European) |
| Encryption | Can encrypt directly, anti-copy |
| Transmit Power | 0 dBm to 30 dBm (Adjustable by software) |
| Software & SDK | DEMO and C#, VC, Java SDK |
| Anti-Thunder | 6000 V |
| Frequency Modulation | Hopping or fixed frequency |
| Antenna | 12 dBi circular polarization |
| Interface | WG 26/34; RS232; RS485; Customized –TCP/IP RJ45; WIFI |
| Case Material | ABS |
| Power Supply | Adapter (into +12 V DC) |
| Read Distance | Up to 82.02 ft (25 m) (according to tag), can adjust by software |
| Read Prompt | Buzzer |
| Storage Temperature | -40 °F to 212 °F (-40 °C to 100 °C) |
| Working Temperature | -4 °F to 176 °F (-20 °C to 80 °C) |
| Dimension | 9.25 in x 9.25 in x 2.24 in (235 mm x 235 mm x 57 mm) |
| Weight | 11.02 in (5 kg) |
