Description
Technical Specifications
| Format Available | Dry Inlay or Wet Inlay or Label |
| Chip | Impinj R6/R6P |
| Substrate | PET |
| Protocol Supported | ISO/IEC 18000-63 EPC Class1 Gen2 ISO/IEC 18000-6C EPC Class1 Gen2 |
| Frequency | 860 MHz to 960 MHz |
| Surface Material | Coated Paper or PET or PP |
| EPC | 96 Bits or 128 Bits |
| User Memory | 0 Bits or 32 Bits |
| Operating Mode | Passive |
| Write Cycles | 100,000 |
| ESD-HBM/CDM | 2000V |
| Reading Range | Up to 42.6 ft (13 m) |
| Temperature | Operation -40 °F to 158 °F (-40 °C to 70 °C) Storage -4 °F to 122 °F (-20 °C to 50 °C) |
| Humidity | 20 % RH to 90 % RH |
| Antenna Size | 2.76 in x 0.55 in (70 mm x 14 mm) |
| Die Cutter Size | 2.91 in x 0.94 in or 2.83 in x 0.79 in (74 mm x 24 mm or 72 mm x 20 mm or customized) |
