| Frequency |
865 MHz to 868 MHz, 920 MHz to 925 MHz, 902 MHz to 928 MHz |
| Protocol |
EPC C1 GEN2 / ISO 18000-6C |
| Engine |
Impinj E 710Impinj R 2000 |
| Antenna |
Circular polarization (4dBi), linear polarization (1.8 dBi) |
| Power |
1 W (30 dBm, + 5 dBm to + 30dBm adjustable) |
| 2 W Optional (33 dBm, for Latin America, etc.)Impinj E710 chip |
| Max Read Range |
7572.17 ft (2308 m) (Almliepnin Hj M37560 tags Size: 25.26 ft x 3.77 ft x 0.14 ft(7.7 m x 1.15 m x 0.042 m)Anti-metal tag, size 130 |
| Fastest Read Rate |
1200 + tags per s (circular polarization) |
| Barcode Scanning (optional) |
| 2D Scanner 1D Symbologies |
UPC/EAN, code128, Code39, code93, Code11, interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, codabar, MSI, RSS, etc. |
| 2D Symbologies |
PDF417, MicroPDF417, composite, RSS, TLC-39, Data matrix, QR code, micro QR code, Azlec, Maxi code; Postal codes: US Post Net, US planet, UK postal, AUSTRALIAN postal, Japan Postal, Dutch Postal (KIX), etc. |
| NFC |
| Protocol |
ISO 14443 A/B, ISO 15693, NFC IP 1, NFC IP 2, etc. |
| Chips |
M 1 card (S 50, S 70), CPU card, NFC tags etc. |
| Range |
7.87 in to 9.68 in (200 mm to 500 mm) |
