Description
Technical Specifications
| Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C |
| RSSI | Support |
| Frequency | 860 MHz to 960 MHz |
| RF Power | 33 dBm ±1 dB (Max) |
| Step Power | 1 dBm |
| Signal Width | <250 kHz |
| Antenna Port | 16 SMA |
| Effective Distance | 12 dBi linear polarized antenna, 30 dBm, standard E41 testing tag 114.8 in (Read:35 m) 3.28 in (Write:1 m) |
| Read Speed | 200tags per s |
| Interface | USB, RS232, RS485, Weigend, RJ45(TCP or IP, UDP) Wi-Fi, Blue tooth and 4G(DTU) 4 GPIO (+5 V TTL level), including 2 GPI and 2 GPO |
| Baud Rate | 115200 bps |
| Operating Voltage | +12.0 V (9 to 24 V) |
| Operating Current | <600 mA or DC12 V |
| Standby Current | <100 mA or DC12 V |
| Operating Temperature | -4° F to 131° F (-20° C to 55 °C) |
| Storage Temperature | -22° F to 185° F (-30° C to +85 °C) |
| Operating Humidity | <95 % RH 77° F (+25° C) Non-condensing |
