Description
Technical Specifications
| Specification | Value |
| Frequency Range | 840 MHz to 960 MHz |
| Read Distance | Up to 65.6ft (20 m) |
| Communication Protocols | ISO 18000-6C or 6B |
| Chipset | Impinj R2000 |
| Antenna Type | Directional |
| Power Consumption | 6 W |
| Operating Temperature | -4° F to 140° F (-20° C to 60° C) |
| Input Voltage | 12 V DC |
| Interface | Ethernet |
| Protocol | EPC C1G2, ISO18000-6B/C |
| Chip | Impinj R2000 |
| Optional Frequency Band | Please tell our sales which band do you want before ordering: ETSI 865 MHz to 868 MHz; JP 916.8 MHz to 920.4 MHz; TW 922.25 MHz to 927.75MHz; ID 923.125 MHz to 925.125MHz; RUS, 866.6 MHz to 867.4 MHz; TEST, 802.75 MHz to 998.75MHz; JP_LBT,916.8 MHz to 920.8MHz |
| Communication Protocol | TCP/IP |
| Antenna Port | 4 TNC ports |
| I/O interface | 2 inputs, 3 outputs |
| Working Mode | Fixed frequency or frequency hopping optional |
| RF Output Power (port) | 33 dBm±1 dBm (MAX) |
| Recognizing Speed | >600 times per S |
