Description
Technical Specifications
| Frequency | 920 MHz to 925 MHz or 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol | ISO18000-6C or EPC C1 GEN2 |
| Antenna Parameters | Linearly polarized antenna (1.8 dbi) or circularly polarized antenna (4 dbi) |
| Display | 5.2 in (13.2 cm) IPS |
| Touch Panel | Corning Gorillas Glass, multi touch panel, gloves and wet hand support |
| Power | Li-On, rechargeable, 8000 mAh |
| Expansion Slot | 1 Slot for SIM, 1 slot for SIM or TF card |
| Audio | Speaker, 2 microphones 4 Front keys, 1 power key, 2 scan keys, 1 multifunctional key |
| Sensors | Gravity sensor, light sensor, proximity sensor |
| CPU | Cortex-A53 Quad Core 1.45 GHz |
| RAM + ROM | 2 GB + 16 GB |
| Expansion | Supports up to 128 GB Micro SD card |
| Camera | 13 MP Autofocus Flash |
| Antenna | Linear Polarization (1.8 dBi) Circular Polarization (4 dBi) |
| Power | 1 W |
| Group Rate | 200 tag per sec |
| R Or W Range | (25 m) 82 ft |
| Drop Specification | Multiple (1.5 m) 4.9 ft drops to the concrete across the operating temperature |
| Tumble Specification | 1000 X (0.5 m) 1.6 ft falls at room temperature |
| ESD | ± 15 KV air discharge, ± 16 conductive discharges |
| Bluetooth | Bluetooth 4.0 BLE |
| Battery Capacity | Rechargeable lithium polymer battery 8000 mAh |
| Power | 1 W (30 dbm, support + 5 dbm to +30 dBm adjustable) |
| Group Read Rate | 200 Tags per second (circular polarization) |
| MOQ | 1 |
| Power Supply | 3.7 V 4000 mAh Li-ion Battery |
| Barcode Scanning | 1D Linear Scanner or 1D Symbologies or 2D Symbologies or 2D Image Scanner |
| Version | English |
| Interfaces | USB 2.0 Type-C, OTG |
| Barcode Scanning (Optional) 1D Linear Scanner (Quad-Core) | Zebra SE965 / Honeywell N4313 |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D Imager Scanner (Quad-Core) | Zebra SE4710 / SE4750 / SE4750MR Honeywell N4313 |
| 2D Imager Scanner (Octa-Core) | Zebra SE4750 / SE4750MR |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. |
| Operating Temperature | – 4 °F to 122 °F (- 20 ℃ to 50 ℃) |
| Storage Temperature | – 40 °F to 158 °F (- 40 ℃ to 70 ℃) |
| Dimensions | 6.4 in X 3.1 in X 0.9 in (164.2 mm × 80 mm × 24.3 mm) |
| Weight | 23 oz (654 g) |
