Description
Overview
Amuse Tech Solutions Medium Range UHF RFID Reader can decode ISO-18000B, EPC. Reading Rang (Max). 32.81 ft to 65.62 ft (10 m to 20 m) Reading. Free SDK and configuration software shapes.
Technical Specifications
| Frequency | 902 MHz to 928 MHZ |
| Tag Air Interface | EPC Class1 Gen2 Standard. Note:(the reader can be made to order compatible two kinds of protocol: the one is EPC Class1 G2 another is ISO18000-6B) |
| Fixing | Vertical (level 360 degree adjustable, angle of gradient Max. 30 degree adjustable) |
| Transmit Power | Max. 30 dBm adjustable |
| Antenna | linear polarization antenna (specially made) |
| Communication Ports | RS232, RS485, Wiegan26, Trigger input interface. |
| Tag Moves Best Speech | 74.5645 mil per hr (120 km per hr) |
| Read Distance | 26.25 ft to 39.37 ft (8 m to 12 m) |
| Size | 10.24 in x 10.24 in x 3.54 in (260 mm x 260 mm x 90 mm) |
