Description
Overview
Amuse Tech Solutions Medium Range Passive Standalone Fixed Remote UHF RFID Reader is completely designed, based on efficient patented digital signal processing algorithm, supports fast tag read or write operation with high identification rate. It can be widely applied in many RFID, application systems such as logistics, access control and industrial production and anti-counterfeiting.
Technical Specifications
| Supported Protocols | ISO18000-6B, ISO18000-6C (EPC GEN2). |
| Working Frequency | ISM 902 MHz to 928 MHz and ISM 865 MHz to 868 MHz, Other frequency standards (customized) |
| Operation Mode | Fixed Frequency or Software Programmable |
| RF Power | 0 dBm to 30 dBm, Software Programmable |
| Reading Speed | Single card average reading is 64 bits, less than 6 ms, Software Programmable |
| Work Mode | Reading Active and reading passive, Software Programmable |
| Communication Ports | N: Wiegand26/34/98, RS485, RS232, USB E: Wiegand26/34/98, RS232, TCP, USB |
| Input Interface | 1 way trigger input |
| Reading Range | 0 ft to 16.40 ft (0 m to 5 m) 0 ft to 26.2 ft (High power 0 m to 8 m) |
| Status Indicators | Buzzer |
| Antenna | 7 dBi circular antenna |
| Power Supply | DC 9 V |
| Operation Temp | -4 °F to 158 °F (-20 °C to 70 °C) |
| Size | 8.46 in x 8.46 in x 1.97 in (215 mm x 215 mm x 50 mm) |
| Weight | 28.21 oz (800 g) |
