Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO 18000 to 6C |
| Standby Mode Current | <80mA (EN high level) |
| Operating Current | 180mA @ 3.5V (26 dBm Output, 77° F (25° C)). 110mA @ 3.5 V (18 dBm Output, 77° F (25° C)) |
| Operating Temperature | -4° F to 158 °F (-20° C to 70° C) |
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C or ISO 18000 to 6B |
| Spectrum Range | 860 MHz to 960 MHz |
| Output Power | 0 dBm to 26 dBm |
| Peak Inventory Speed | >50 tags per sec |
| Baud Rate | 115200 bps (The default and recommended) 38400 bps |
| Host Communication | USB 2.0 RS-232 Wiegand 26 Wiegand 34 |
