Description
Technical Specifications
| Working Frequency | US standard 902 MHz to 928 MHz Other frequency standards (customized) CN standard (920 MHz to 925 MHz) |
||
| Protocol | ISO18000-6C (EPC GEN2) ISO18000-6B |
||
| Operation Mode | Fixed Frequency or FHSS or Software Programmable | ||
| Antenna Parameter | 2 dBi circularly polarized antenna (built-in) | ||
| Output Power | 12.5 dBm to 26 dBm (Adjustable by software) | ||
| Reader & Write Range | Reading Rang (Max): 1.6 ft (0.5 m) Related to the card or the environment） Writing Rang (Max): 0.6 ft (0.2 m) Related to the card or the environment） |
||
| Working Mode | Active Mode Passive Mode Answer Mode (Not recommend) |
||
| Voltage | DC + 5 V | ||
| Data Interface | USB to virtual keyboard input USB to virtual serial port (Customized) |
||
| Working Temp | -4 °F to 131 °F (-20 ℃ to 55 ℃) | ||
| Storage Temp | -40 °F to 185 °F (-40 ℃ to 85 ℃) | ||
| Size | 0.03 in x 2.75 in x 0.59 in (110 mm × 70 mm × 15 mm) |
||
| Net or Gross Weight | 0.33 lb or 0.55 lb (150 g or 250 g) | ||
