Description
Technical Specifications
| Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHz (Adjustable) |
| Protocol | Modbus/ISO18000-6C (GB) |
| Interfaces | Standard-WG26/34, RS232/485, USB, Relay (optional) |
| Work Principle | FHSS or FF |
| Work Mode | Timing or Active or Trigger |
| Output Power | 0 dBm to 30 dBm (Adjustable) |
| Power Supply | +9 V to +25 V, >2 A |
| Power Dissipation | < 3 W per hour |
| Work Tip | Buzzer |
| Working Humidity Range | (20 % to 95 %) (No condensation) |
| Reading Distance | 0 ft to 3.28 ft (0 m to 1 m) (Adjustable) |
| Storage Temperature Range | -20 % 167 °F (+75 °C) |
| Working Temperature Range | 14 °F to 131 °F (-10 °C to +55 °C) |
| Size | 3.74 in x 3.74 in x 1.57 in (95 mm x 95 mm x 40 mm) |
| Weight | 3.75 lb (1.7 kg) |
