Description
Technical Specifications
| Frequency | Working Frequency: 860 to 960mhz, 902 to 928MHz or 865 to 868Mhz |
| Protocol | ISO18000-6C (EPC Gen2) |
| Usage | Car Parking System |
| Card Type | ISO18000-6C (EPC Gen2) UHF Card |
| Antenna Specifications | 8dBi circularly polarized antenna |
| Read Range | 0 to 26.2 ft (8 m) (depends on the tags) |
| Card Reading Speed | 400 times per 1 s |
| Communication Port | RS232, RS485, WG26, WG34, Trigger, Relay(Optional), RJ45(Optional), WIFI(Optional), POE(Optional), USB(Optional) |
| Net | RJ45 supports TCP Client/Server, Modbus, DNS, DHCP. WIFI supports TCP Client. 4G supports TCP Client. HTTP Protocol (Optional), MQTT(Optional), LLRP(Optional) |
| Power Supply | 12 V DC |
| Output Power | 0 to 26 dBm |
| Operating Temperature | 95 °F to 140 °F (-35 ℃ to +60 ℃) |
| Storage Temperature | 140 °F to 176 °F (-50 ℃ to +80 ℃) |
