Description
Technical Specifications
| Frequency Range | 902 MHz to 928 MHZ (can be adjusted according to different countries or regions) |
| Air Interface Protocol | EPCglobal UHF ISO-18000-6C (EPC G2), ISO-18000-6B |
| Antenna Polarization | Right-hand circular polarization |
| Half Power Lobe Width | Horizontal plane: 65° Vertical plane: 60° |
| Frequency Modulation Method | Broad spectrum frequency modulation (FHSS) or fixed frequency, can be set by software |
| RF Output | 30 dBm adjustable; 50 Ω load |
| Communication Interface | RS232 or RS485 or Wiegand 26 or 34 or TCP/IPor wireless communication (optional) |
| Communication Rate | The serial port rate is 9600 bps to 115200 bps，RJ45 10 Mbps |
| GP I/O Interface | I/O interface (12 pin + 4 pin) |
| Power Consumption | Average power < 10 W |
| Application Software Interface | Provide API development kit and VC, VB, Java application routines |
| Label Operation Performance | |
| Reading Distance | 12 dBi antenna configuration, typical reading distance is 9.8 ft to 49.2 ft (3 m to 15 m) (related to tag performance) |
| Mechanical Electrical Performance | |
| Power Supply (Aviation Connector) | Equipped with 220 V AC input, +12 V or 3 A DC output power converter |
| Indication Mode | Panel configuration working status LED indicator |
| Radom Material | ABS engineering plastics |
| Radome Color | White or gray |
| Installation Method | Pole installation |
| Support Rod Diameter | 1.37 in x 1.96 in (35 mm to 50 mm) |
| Degree Of Protection | IEC IP67 |
| Lightning Protection | DC grounding |
| Interface Mode | IP67 grade waterproof quick connector |
| Working Temperature | -4 °F to 149 °F (-20 ºC to +65 ºC) |
| Humidity | 5 % to 95 %, non-condensing |
| Size | 17.71 in x 17.71 in x 2.75 in (450 mm x 450 mm x 70 mm) (not including mounting bracket and external wiring) |
| Weight | 6.61 lb (3 kg) |
