Description
Technical Specifications
| Working Frequency | 840 MHz to 960 MHz optional, frequency hopping function |
| Protocol | ISO18000-6C |
| Output Power | 33 dBm ± 1 dBm (MAX） |
| Power Output Step | 1 dBm |
| Antenna Polarization | Circular polarization |
| Antenna Gain | 15 dBi |
| Identify Distance | >49.2 ft (15 m) (related to label and environment) |
| Cable Interface | A 4-way SMA interface RJ45 RS 232/ RS 485 |
| Radio Interface | Wiegand 26/34 WIFI (optional) |
| Working Voltage | DC 12V |
| Normal Current | <100mA /DC 12V |
| Maximum Current | <1000mA /DC 12V |
| Working Temperature | -4 °F to +140 °F (-20 ℃ to +60 ℃) |
| Storage Temperature | -40 °F to +176 °F (-40 ℃ to +80 ℃) |
| Working Humidity | 5 % to 95 % (No condensation) |
| Overall Dimensions (RxD) | 6.5 in x 4.33 in x 1.1 in (165 mm x 110 mm x 28 mm) |
| Weight | 1.1 lb (0.5 kg) |
