Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC Global UHF Class 1 Gen 2 or ISO 18000-6C |
| Read Distance | 19.6 ft to22.9 ft (6 m to 7m) (Tested tag: impinj E41b) |
| Output Power | 0 dbm to 33 dbm |
| Operating System | Android 12.0 |
| LCD | 5 in (12.7 cm) or 1280 X 720 or IPS or 180° view angle |
| Battery | 6000 mAh Li-polymer battery |
| Wifi+BLE+3G Or 4G | Supported |
| RAM + ROM | 2G + 32G (4G + 64G) |
| UHF Antenna | 4 dBi dielectric antenna |
| Materials | CNC aluminum + nylon (Bayer) |
| CPU | Quad-core Cortex-A17 or 1.8 GHz |
| GPU | ARM Mail- T764 or High-performance 3D engine |
| Touchscreen | (1.1 mm) 0.04 in thickness tempered glass or 10-dottouch |
| Hot Swapping Battery | Pistol Style Hot- swapping Battery System |
| PSAM | PSAM X 2 |
| Power | 6000 mAh Chargeable Li-polymer Battery |
| Card Slots | Micro SIM Card Slot or PSAM Card Slot X 2 |
| USB Interface | Micro USB or MOLEX connector or Operating life 10,000 cycles |
| Audio | Large Speaker Stereo System |
| Vibrator | Button style or 0.3 in (10 mm) diameter |
| Charge Indicator | Bicolor LED |
| WIFI | IEEE802.11b or g or n |
| Buzzer | 0.4 in X 0.3 in (12 mm X 9.5 mm) or 2300 ± 300 Hz |
| 1D Barcode (Optional) Engine |
Motorola EM1350 |
| Support | UPC/EA Symbol SE955N / Code128 / Code39 / Code93 / Code11/ Interleaved 2 of 5 / Discrete 2 of 5 / Chinese 2 of 5 / Codabar / MSI / RSS etc. |
| 2D Barcode (Optional) Engine |
Honeywell N3680 |
| Support | Data matrix / QR Code / PDF417 / US Planet / UK Postal etc. |
| Humidity | 5 % RH to 95 % RH (Noncondensing) |
| Safety Drop Height | (2 m) 6.56 ft |
| Operating Temperature | -4 °F to 140 °F (-20 °C to + 60°C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to + 70 °C) |
| Size | 3.9 in X 1.1 in X 0.1 in (100 mm x 30 mm X 3 mm) |
| Weight | 20.4 oz (580 g) |
