| Features |
Wireless connection, Ultra-low power consumption, Remote active awakening, Quick start |
| Use |
Guests will be able to make video voice calls and take short videos. The owner will not need to open the door to know the information |
| Alarm Push |
Push for 1 second |
| Number Of Users Online |
Multiple users are online simultaneously |
| Dynamic DNS |
Bring your own dynamic domain name |
| Processor |
A powerful, high-performance, programmable media HI Silicon processor with built-in ARM926 @max. 440 MHz and high-speed video coprocessor |
| Ccd |
1 in / 2.7 in 1080 p scan CMOS sensor |
| Sensor Performance |
Support automatic white balance, automatic gain control, automatic backlighting compensation |
| Snr |
≥39 dB |
| Lens/Visual Angle |
0.1 in (2.6 mm), F 2.0 / 155° |
| Led |
Double filter automatic switching, six 850 nm high power infrared lamp, night vision 393.7 in (10 m) |
| IR Control |
IR opens night vision, Automatic detection of infrared and ICR, IR shuts the night vision function off the infrared and the ICR is fixed in daily viewing mode |
| Compression Standard |
H.264 Main Profile / H.264 Baseline Profile / MJPEG / JPEG Baseline |
| Video Coding |
More stream:1080 P / 15 fps + 720 P / 15 fps + VGA / 30 fps + QVGA / 30 fps + 1080 P at 1 fs JPEG snap |
| Resolution |
1080 P |
| Input |
1 channel built-in – 48 dB microphone |
| Output |
Built-in speaker (8 Ω 1 w) |
| Interphone |
Two – way voice – speak, bring back the echo cancellation |
| Compression Standard/ Code Rate |
ADPCM / 32 kbps |
| Network Protocol |
TCP/IP, HTTP, TCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP, RTSP, P2P |
| Wireless Network |
802.11 b / g / n |
| Wireless Network Security |
WPS Security encryption |
| Wireless Connection |
One-button WIFI configuration |
| Video Mode |
Mobile detection video, doorbell button trigger video, manual video |
| Storage |
The TF card stores the maximum support for 32gb |
| Power |
Battery power supply two section 18650 core international general |
| Power Consumption |
Standby current 200 uA working current 170 MA |
| Work Environment |
Working temperature: 14 °F to 122 °F (- 10 °C to 50 ℃), humidity is <95% |
| Installation |
Door wall mounting |
| Material |
ABS |
| Product Size |
5.6 in x 1.8 in x 1.08 in (140 mm x 45.5 mm x 27.5 mm) |
| Product Weight |
1.2 in (90 g) / No battery |
