Description
Technical Specifications
| Parameters | |
| Working Frequency | CN standard (920 MHz to 925 MHz) US standard (902 MHz to 928 MHz) Other frequency standards (customized) |
| Protocol | ISO18000-6C (EPC GEN2) ISO18000-6B |
| Operation Mode | Fixed Frequency or FHSS or Software Programmable |
| Antenna Parameter | 2 dBi circularly polarized antenna (built-in) |
| Output Power | 12.5 dBm to 26 dBm (Adjustable by software) |
| Reader & Write Range | Reading Rang (Max): 1.6 ft (0.5 m) (related to the card or the environment) Writing Rang (Max): 0.6 ft (0.2 m) (related to the card or the environment) |
| Working Mode | Active mode Passive mode Answer mode (Not recommend) |
| Interface | |
| Voltage | DC +5 V |
| Data Interface | USB to virtual keyboard input USB to virtual serial port (Customized) |
| Working Environment | |
| Working Temp | -4 °F to +131 °F (-20 ℃ to + 55 ℃) |
| Storage Temp | -40 °F to +185 °F (-40 ℃ to + 85 ℃) |
| Physical Parameter | |
| Size | 4.13 in x 2.56 in x 0.59 in (105 mm x 65 mm x 15 mm) |
| Net Weight | 7.05 oz (200 g) |
