Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO/IEC 18000-6C EPC Class1 Gen2 |
| Chip | M4QT |
| Material | Coated Paper/ PET/Synthetic paper/Thermal paper/customization |
| Working Mode | Passive |
| IC Life | 100,000 Programming cycles, 10years data retention |
| Printing | Full Color Printing, Logo, Barcode, QR code, etc. |
| Operating Temperature or Humidity | -13 °F to + 122 °F (-25 °C to 50 ºC) or 20 % RH to 80 % RH |
| Storage Temperature or Humidity | 73.4 °F ± 41 °F (+23 °C ± 5 °C) or 50 % RH ± 10 % RH (Without condensation) |
| Application or Solution | Secure Admission Control or Cashless Payment Membership and loyalty programs |
| Antenna | 2.60 in x 1.02 in
(66 mm x 26 mm) Aluminum Etching |
| Wet Inlay or Label Size | 2.75 in x 1.18 in
(70 mm x 30 m) or customization |
