Description
Overview
Amuse Tech Solutions Fast UHF Reading and Writing Card Reader RFID Desktop is a professional reader specially designed and developed by our company for label information input. It has excellent protection performance and read and write performance. It can realize automatic group write and single write, and quickly read and write labels. The appearance of the product is simple and generous, small and beautiful, light weight and easy to carry. The software provided with the reader can quickly import and export Excel tables, automatically input data intelligently, realize fast binding and association of labels and data information, reduce tedious manual input, and improve work efficiency. It adopts USB communication design, supports virtual keyboard input, and data communication, which is convenient for customers to realize complex applications in various modes. The card issuer adopts a simple and atmospheric design style, classic black high-density resin material, with black aluminum alloy edge shell, highlighting the industrial beauty.
Features
- Classis industrial shape and atmospheric design style
- Easy to operate with USB communication design
- Perfectly integrated Antenna with the reader
- Strong label processing capabilities and automatic card writing
- Easy to develop application and SDK development kit
- Directly encrypted, anti-copy, ensure the security of data
Technical Specifications
| Physical Parameters | |
| Materials | Alloy |
| Class Of Protection | IP53 |
| Main Functions | |
| Frequency | GB, 920 MHz to 925 MHz or 840 MHz to 845 MHz FCC, 902 MHz to 928 MHz ETSI, 865 MHz to 868 MHz |
| Protocol | ISO 18000-6C/6B, EPC C1G2 GB/T 29768-2013(Optional) GJB 7377. 1-2011/7377. 1-2018A Various temperature and humidity label protocols |
| Communication Interface | |
| RF Output Power (Port) | 0 dBm to 27 dBm ±1 dB (21 dBm is recommended) |
| Output Power Regulation | 1 dB step |
| Band Stability | ≤ ±10 ppm |
| Read Distance | 0 in x 23.6 in (0 cm to 60 cm) |
| Power Supply | USB (DC 5 V) |
| Working Environment | |
| Operating Temperature | -4 °F to 140 °F (-20 °C to +60 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to +85 °C) |
| Humidness | 10 % to 95 % RH no condensation |
| Size | 5.39 in x 4.13 in x 0.6 in (137 mm × 105 mm × 16 mm) |
