Description
Technical Specifications
| Shell Material | Aluminum alloy |
| RF Interface | SMA outer nut head |
| Antenna Interface | 8 Ports |
| Working Frequency (Performance Parameters) | 902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU) |
| Communication Port (Performance Parameters) | RS232, TCP/IP |
| Protocol (Performance Parameters) | EPC C1 Gen2, ISO 18000-6C |
| Input / Output Port (Performance Parameters) | 2 Channel relay output (selectable), 2 channel I/O input |
| Power (Performance Parameters) | 20 dBm to 30 dBm |
| Power Supply (Performance Parameters) | 12 V or 3 A |
| Development Package (Performance Parameters) | Provide DEMO software, SDK & C#, VC, Java development routines |
| Other Configuration (Performance Parameters) | 1M/8M large capacity Flash storage, save when power down, POE power |
| Item Size (Performance Parameters) | 5.9 in x 5.3 in x 14.1 in (15 cm x 13.6 cm x 36 cm) |
| Net Weight (Performance Parameters) | 1.1 lb (0.5 kg) |
