High-Performance UHF RFID Label Sticker with M4 Chip for Versatile Tracking – Amuse Tech Solutions

High-performance UHF RFID tag with 4QT chip, ISO/IEC 18000-6C, ideal for inventory, asset, and supply chain management. Durable PET substrate, wide read range

SKU: ATSUHF-250
Category:

Description

Technical Specifications

Operating Frequency 860 MHz to 960 MHz
Protocol ISO/IEC 18000-6C, EPC Class1 Gen2
Chip MONZA 4QT
Memory 128 bits or 512 bits
Reading Range 3.3 ft to 19.7 ft(1 m to 6 m) depend on reader and tag size
Substrate PET
Surface Material PET or Paper or PVC or PP
Antenna Process Aluminum ETCH(AL10um)
Working Mode Passive
Write Cycles 100000
Inlay Format in roll
Some Common Uses For RFID Applications Include
  • Pet and livestock tracking
    Inventory management
    Asset tracking and equipment tracking
    Inventory control
    Cargo and supply chain logistics
  • Vehicle tracking
    Customer service and loss control
  • Improved visibility and distribution in the supply chain
    Access control in security situations
    shipping
    healthcare
    manufacturing
    retail sales
    tap-and-go credit card payments
Operating Temperature / Humidity. – 40 °F to + 158 °F(- 40 to 70 ºC) 20 % to 90 % RH
Storage Temperature / Humidity – 4 °F to + 122 °F(- 20 to 50 ºC) 20 % to 90 % RH(Without condensation).
Size Antenna size: 1.73 in x 1.73 in(44 mm X 44 mm)Wet inlay size:(50 mm X 450 mm) or Customized
Label size: 1.97 in x 17.7 in(50 mm X 450 mm) or Customized
