Description
Features
- RHCP Circular polarization
- SMA or upon your request connector
- 3 dBi gain
- 920 MHz to 925 MHz frequency
Technical Specifications
| Center Frequency | 920 MHz to 925 MHz |
| Gain | 3 dBi |
| VSWR | 1.9 |
| Polarization | RHCP Circular polarization |
| Impedance | 50 Ω |
| Maximum Input Power | 50 W |
| Connector | SMA or upon your request |
| Operating Temperature | -22 °F to 158 °F (- 30 ℃ to + 70 ℃) |
| Storing Temperature | -4 °F to 140 °F (- 20 °C to + 60 °C) |
| Reflecting Plate Size | 1.97 in x 1.97 in x 0.04 in (50 mm x 50 mm x 1 mm) |
| Dimension | 1.57 in x 1.57 in x 0.16 in (40 mm x 40 mm x 4 mm) |
| Net Weight | 1.76 oz (50 g) |
