Description
Technical Specifications
| Body Material | Aluminum alloy (Alufer) |
| Input Voltage | 12 V to 24 V DC |
| Standby State Current | < 70 mA |
| Sleep State Current | < 100 uA |
| Maximum Working Current | 800 mA +/- 5 % at DC 12 V input |
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Operating Spectrum Range | 860 MHz to 960 MHz |
| Output Power | 0 dBm to 33 dBm |
| Output Power Accuracy | +/- 1 dB |
| Flatness Of Output Power | +/- 0.25 dB |
| Acceptance Sensitivity | < -85 dBm |
| Peak Speed Of Inventory Label | 700 tags per s |
| Label RSSI | Sustain |
| Antenna Connection Protection | Sustain |
| Ambient Temperature Monitoring | Sustain |
| Working Mode | Stand-alone or intensive |
| Communication Interface | RS232 & TCP/IP |
| GPIO | 2-way input, 2-way output |
| Maximum CD Ratunication | Default 115200 bps (38400 or 460800 configurable) |
| Heat Dissipation Mode | Air cooling |
| Working Temperature | -22 °F to 158 °F (-30 °C to +70 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to +85 °C) |
| Working Humidity | < 95 % 77 °F (+25 °C) |
| Weight | 2.5 lb (1.16 kg) |
