Description
Features
- Linear polarization
- DC ground lightning protection
- SMA Female connector
- Bottom connector position
- Aluminium reflector material
Technical Specifications
| Frequency Range | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | ISO 18000-6C |
| Polarization | Linear |
| Gain | 12 DBi |
| Horizontal Beam Width | Horizontal 45 ° Vertical 45 ° |
| F or B Ratio | ≥ 20 |
| VSWR | ≤ 1.4 |
| Impedance | 50 Ω |
| Maximum Power | 50 W |
| Lightning Protection | DC ground |
| Connector | SMA Female |
| Connector Position | Bottom |
| Wind Loading Area | (0.66 ft 2) (≤ 0.2 m 2) |
| Rated Wind Velocity | 196.85 ft per s (60 m per s) |
| Reflector Material | Aluminium |
| Radome Material | Organic glass |
| Radome Colour | Black |
| Operating Temperature | – 40 °F to 158 °F (- 40 °C to 70 °C) |
| Size | 47.24 in x 7.09 in x 0.79 in (1200 mm x 180 mm x 20 mm) |
| Packing Size | 51.18 in x 7.87 in x 0.98 in (130 cm x 20 cm x 2.5 cm) |
| Antenna Weight | 7.72 lb (3.5 kg) |
| Packing Weight | 7.72 lb (3.5 kg) |
