Description
Features
- High gain
- Full day working
- Optimized dimension
- Vertical or horizontal polarization
Technical Specifications
| Frequency Range | 902 MHz to 928 MHz |
| Polarization | Vertical |
| Gain | 15 dBi |
| Half Power Beam Width | H 120 ° V 7 ° |
| Front To Back Ratio | ≥ 18 dB |
| Input Impedance | 50 Ω |
| VSWR | ≤ 1.5 |
| Sidelobe Suppression For First Sidelobe Above Horizon | 15 dB |
| Maximum Input Power | 400 W |
| Lightning Protection | DC Ground |
| Input Connector Type | N Female |
| Radome Material | UPVC |
| Radome Color | Gray |
| Mechanical Tilt | 0 ° to 10 ° |
| Rated Wind Velocity | 196.85 ft per s (60 m per s) |
| Waterproof Standard | IP67 |
| Mounting Way | Pole holding |
| Mounting Hardware | 1.38 in to 3.54 in (35 mm to 90 mm) |
| Operating Temperature | – 40 °F to 140 °F (- 40 °C to 60 °C) |
| Dimensions | 86.61 in x 11.02 in x 4.92 in (2200 mm x 280 mm x 125 mm) |
| Antenna Weight | 31.97 lb (14.5 kg) |
