Description
Features
- High gain
- Low VSWR
- Pleasing appearance
- Medium size
- Double waterproof design with waterproof ring and silica gel
- Rib reinforcement design for shell
- Suitable for various severe environments
Technical Specifications
| Frequency Range | 902 MHz to 928 MHz |
| VSWR | ≤ 1.3 to 1 |
| Gain | > 9 dBic |
| H Side HPBW | 70 ° |
| E Side HPBW | 70 ° |
| Polarization | Circular Polarization |
| Relative Humidity | 5 % to 95 % |
| Impedance | 50 Ω ± 1 Ω |
| Connector Type | N Female |
| Material | Engineering plastics ASA and aluminum |
| Color | Milk white |
| Production Class | IP67 |
| Operating Temperature | – 40 °F to 185 °F (- 40 ℃ to + 85 ℃) |
| Storage Temperature | – 40 °F to 185 °F (- 40 ℃ to + 85 ℃) |
| Size | 10.16 in x 10.16 in x 1.42 in (258 mm × 258 mm × 36 mm) |
| Weight | 2 lb (0.91 kg) |
