High-Gain Directional DAS Antenna with Fixed Mount, 4 dB or 6 dB, Female Connector – Amuse Tech Solutions

DAS Antenna: 806 MHz to 960 MHz or 1710 MHz to 2700 MHz, 4 dB or 6dB Gain, 50 W, 90±15(°) N Female, V Pol, -107 dBm PIM, DC Ground, 6.57 in x 6.57 in x 6.88 in, 3.30 lb

SKU: ATSUHF-225
Category:

Description

Technical Specifications

Type DAS Antenna
Frequency 806 to  960 or 1710 to 2700 (MHz)
Gain 4 or 6
VWB 100(°)
HBW 90±15(°)
Polarization V
PIM ≤ -107 (dBm)
Impedance 50
Power Handling 50(W)
Connector N Female
Grounding DC Ground
Single Package Size 6.57 in x 6.57 in x 6.88 in (16.7 cm X16.7 cm X17.5 cm)
Single Gross Weight 3.30 (1.500 kg)
