Description
Features
- Provides a means of communicating with a transponder (RFID tag)
- Provide the energy for RFID tags to communicate
- Receives the radio frequency signal from reader and transmits it to RFID tag chip
- The data signal in the RFID tag chip is transmitted back to the reader
- Resist all kinds of interference to ensure the stable signal transmission
Technical Specifications
| Frequency Range | 902 MHz to 928 MHz |
| Gain | 10.5 dBi |
| Beam Width | Horizontal 36 ° Vertical 70 ° |
| VSWR | ≤ 1.3 |
| Lightning Protection | Direct ground |
| Impedance | 50 Ω |
| Polarization | Circular polarization |
| Axial Ratio | ≤ 2 |
| Maximum Power | 50 W |
| Connector | SMA J or customer specified |
| Connector Position | Lateral extraction |
| Reflector Material | FR4 |
| Radome Color | White |
| Operating Temperature | – 40 °F to 131 °F (- 40 °C to 55 °C) |
| Dimension | 17.72 in x 7.87 in x 0.87 in (450 mm x 200 mm x 22 mm) |
| Antenna Weight | 1.98 lb (0.9 kg) |
