Description
Features
- Automatic scan Com Port or Network
- Support firmware upgrade
- Support
- Multiple country languages
- Global Frequency (860 MHz to 960 MHz)
- Password mode
- Read specify tag
- Relay
- Data cache
- Multiple customizable communication protocols
- Remote listening
- RSSI
Technical Specifications
| Engine | High performance chip |
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO 18000 -6 C (EPC C1G2) |
| Built In Antenna | 6.85 dBm (9 dBi) circular antenna |
| Work Mode | Active or trigger or answer or password mode |
| RF Power | 2 watts (33 dBm ) |
| Read Distance | 32.8 ft to 65.6 ft (10 m to 20 m) |
| Interface | RS 232 or G or Relay or TCP or IP or POE or USB or TTL or RS 485 and WIFI |
| Power Supply | 9 V to 24 V |
| Reader Size | 12 in X 12 in X 2.95 in (305 mm X 305 mm X 75 mm) |
| Operating Temperature | 50°F to 131 °F (10 °C to 55°C) |
| Storage Temperature | 68 °F to 167 °F (20 °C to 75 °C) |
| Package Size | 16.54 in X 13.78 in X 4.33 in (420 mm X 350 mm X 110 mm) |
| Net Weight | 4.40 Ib (2 kg) |
