Description
Overview
Amuse Tech Solutions EPC Gen2 UHF desktop reader is a high-performance UHF RFID reader. It is designed upon dedicated RFID Engine ASIC with fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.
Technical Specifications
| Spectrum Range | 865 MHz to 868 MHz, 902 MHz to 928 MHz |
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Input Voltage | 3.5 V to 5 V |
| Standby Current | < 80 mA |
| Output Power Precision | 10 dBm, 18 dBm to 26 dBm |
| Output Power Flatness | +/- 0.2 dB |
| Receive Sensitivity | < -70 dBm |
| Peak Inventory Speed | > 50 pc per s |
| Tag Buffer Size | 200 per piece at 96 bits EPC |
| Tag RSSI | Supported |
| Host Communication | USB 2.0, RS 232, Wiegand 26, Wiegand 34 |
| Max Baud Rate | 115200 bps (Default and Recommended) 38400 bps |
| Antenna | 2 dBi Circular Polarization Antenna. Read range: 31.4 in to 78.7 in (80 cm to 200 cm) (Tested with Impinj E41b tag) |
| Operating Temperature | -4 °F to +158 °F (-20 °C to +70 °C) |
| Storage Temperature | -4 °F to +185 °F (-20 °C to +85 °C) |
| Humidity | < 95 % 77 °F (+25 °C) |
| Specification | 4.72 in x 3.34 in x 0.78 in (120 mm x 85 mm x 20 mm) |
| Weight | 4.12 oz (117 g) |
