Description
Features
- It is large in size
- Has a back cover on the bottom
- Can be built into an all in one machine
- With built in modules.
- Long reading and writing distance and high stability.
Technical Specifications
| Protocol | ISO IEC 18000 6B 6C EPC C1Gen2 |
| Frequency Range | 902 MHz 928 MHz |
| Gain | 8 dBi |
| Beam Width | Hor 45 ± 1, Ver 75 ± 1 |
| Reflector Material | FR4 Copper Clad Laminate |
| VSWR | ≤1.5 |
| Impedance | 50 |
| Polarization | Circular polarization |
| Max Power | 50 |
| Connector | Internal Lead RG316 Connector Customized |
| Radome Material | ABS |
| Radome Colour | White |
| Operating Temperature | −40 °F to 140 °F (-40°C to 60°C) |
| Dimension | 13.23 in x 5.12 in x 0.79 in (336 mm x 130 mm x 20 mm) |
| Antenna Weight | 1.30 lbs (0.59 kg) |
