Description
Features
- Circular polarization
- DC ground lightning protection
- SMA Female connector
- PVC radome material
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Gain | 1 dBi |
| Polarization | Circular |
| VSWR | ≤ 1.8 |
| F Or B Ratio | ≥ 20 |
| Impedance | 50 Ω |
| Maximum Power | 50 W |
| Lightning Protection | DC Ground |
| Connector | SMA Female |
| Radome Color | Black |
| Radome Material | PVC |
| Operating Temperature | – 4 °F to 131 °F (- 20 °C to 55 °C) |
| Packing Size | 3.15 in x 3.15 in x 1.18 in (80 mm x 80 mm x 30 mm) |
| Dimension | 2.44 in x 2.44 in x 0.04 in (62 mm x 62 mm x 1 mm) |
| Net Weight | 0.44 lb (0.2 kg) |
| Gross Weight | 0.88 lb (0.4 kg) |
