Technical Specifications
| Performance Specifications | |
| Frequency Range | 840 MHz to 960 MHz adjustable |
| Protocol | EPC C1 GEN2 / ISO18000-6C |
| Frequency Band | GB 920 MHz to 925 MHz840 MHz to 845 MHz FCC902 MHz to 928 MHz |
| Chip | Impinj R 2000 |
| Read Range | 0 ft to 19.6 ft (0 m to 6 m) |
| Processor | 2.5 GHz or 2.3 GHz 8 core |
| RAM+ROM | 3 GB + 32 GB or 4 GB + 64 GB or 6 GB + 128 GB |
| Antenna Gain | 4 dBi |
| Communication | wifi, bluetooth |
| Power | |
| Power Supply | 12 V, 3 A |
| Power Consumption | 1 W |
| Operating Environment | |
| Operating Temperature | -4 °F to +122 °F (-20 ºC to +50 ºC) |
| Storage Temperature | -40 °F to +158 °F (-40 ℃ to +70 ℃) |
| Working Humidity | < 95 % 77 °F (+ 25 °C) |
| Physical Specifications | |
| Dimension | 7.69 in x 6.09 in x 1.06 in(195.4 mm x 154.4 mm x 27 mm) |
| Net Weight | 23.07 oz (654 g) |
