Description
Technical Specifications
| Frequency | 902 MHz to 928 MHz FCC |
| Air Protocol | EPC global UHF Class 1 Gen 2 ISO 18000-6C |
| Material | Industry grade plastics |
| Input Voltage | DC 3.5 V to 5 V |
| Standby Current | <80 mA |
| Work Current | 310 mA at DC 3.5 V 26 dBm |
| Read Range | Up to 1.6 ft (0.5 m) |
| Write Range | Up to 0.6 ft (0.2 m) |
| Output Power | 0 dBm to 26 dBm |
| Output Power Precision | ± 1 dB |
| Output Power Flatness | ± 0.2 dB |
| Tag Buffer Capacity | 200 tags at 96-bit EPC |
| Reading Rate | > 50 tags per s |
| Host Communication | USB 2.0 |
| Band Rate | 115200 bps |
| Cooling Mode | Air cooling |
| Operating Temperature | -4 °F to 131 °F (-20 °C – + 70 °C) |
| Storage Temperature | -4 °F to 185 °F (-20 °C – + 85 °C) |
| Humidity | 5 % RH to 95 % RH (no condensation) |
| Dimensions | 3.9 in x 2.8 in x 0.8 in (100 mm x 72 mm x 21 mm) |
| Weight | About 3.5 oz (100 g) |
