Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC C1 GEN2 or ISO18000-6C |
| Operating System | Android 6.0 |
| LED | 5.2 in (13.2 cm) IPS LTPS |
| Touch Screen | Multi-touch panel cornigrade 3 glass toughened screen 5.0MP |
| Front Camera | 13 MP Autofocus with flash |
| Rear Camera | 8 Ω or 0.8 waterproof hornx 1 |
| CPU | MTK 6762-8 |
| RAM or ROM | 2 GB + 16 GB (4 cores) or 3 GB +32 GB (4G+ 64G) |
| Battery Capacity | 3.7 V or 4300 mAH |
| Battery Life | About 8 hrs (standby time >300 h) |
| Battery | Irremovable polymer lithium-ion battery |
| Speed | 2.0 Ghz |
| Built in | Supported ISO or IEC 1443A protocol card reading distance: 0.3 in to 1.1 in (7.6 mm to 27.9 mm) |
| WIFI module | WIFI 802.11 b/g/n/a/ac frequency 2.4 G + 5 G dual band WIFI |
| 2G or 3G or 4G |
CMCC 4M：LTE B1, B3, B5, B7, B8, B20, B38, B39, B40, B41 WCDMA 1 or 2 or 5 or 8 GSM 2 or 3 or 5 or 8 |
| GPS | Supported |
| HF | 13.56 MHz, support 14443A/B;15693 agreement, effective recognition distance 1.1 in to 1.9 in (3 cm to 5 cm) |
| QR code | Zebra se4710 & NLS-CM60&NLS-N1y Optical resolution: 5mil Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse Scanning speed: 50 times per s Support code type: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse |
| Size | 7.0 in X 3.2 in X 0.6 in (178 mm X 83 mm X 17 mm) |
| Weight | 8.5 oz (242 g) |
