Description
Technical Specifications
| Frequency | 902MHz to 908MHz or 865MHz to 868MHz or customize other frequency |
| Protocol | ISO18000-6C (EPC gen2) and ISO18000-6B |
| Receive Sensitivity | <-85 dBm |
| Reading Speed | Multi tag 700pcs per s,single tag 2000times per min |
| Max Bandrate | 115200bps |
| Data | Standard: RS232,RS485,Wiegand26 or 34,RJ45(optional) |
| Data Input Port | Trigger input one team, Anti-collision and multi-reading |
| Communication Ports | RS232,RJ45(TCP or IP) |
| GPIO | 2 inputs optical coupling 2 outputs optical coupling |
| Antenna | External connect different gain antenna |
| Tag Buffer Capacity | 1000 tags at 96 bit EPC |
| Peak Inventory Speed | >700 tags per s |
| Reading Clue | Buzzer and LED |
| Antenna | External connect antenna |
| Power Supply | DC 9V per 12V |
| Reading Range | More than39.37 ft (12m),related to external antenna |
| Operation Temp | -4 °F to 131 °F (-20 ℃ to +55 ℃) |
| Dimension | 8.27 in x 7.87 in x 1.18 in (210 mm x 200 mm x 30 mm) |
| Weight | 3.97 lb(1.8 kg) |
