Description
Features
- Can customize size for customers
- Logo can be printed
- Can be lasered with barcode
- Resistant to acid-base
- Convenient for installation
Technical Specifications
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Chip | Alien H3 (or Impinj M4QT chip) |
| Communication Interface | RFID |
| Special Features | Waterproof or Weatherproof, anti-metal |
| Material | PC, Ceramic |
| Reading Distance | 19.6 ft to 32.8 ft (6 m to 10 m) |
| Options | Pre-encoding, Barcode laser, logo |
| Memory | EPC 96 bits User 496 bits |
| Read or Write | Yes (EPC and User) |
| Data Storage | 50 Years |
| Installation Method | Special tape |
| Drop Test | 3.2 ft (1 m) high, 200 drop test passed |
| Read Distance on Metal Surface | Up to 29.5 ft (9 m) (EIRP = 4 W) Up to 19.6 ft (6 m) (With ATID AT880 handheld reader) |
| RF Performance Consistency Test | 100 % tested |
| Alcohol Test | 95 % alcohol test passed |
| Gasoline Test | Passed |
| Storage Humidity | 5 % to 95 % |
| High & Low Temperature Shock Test | – 40 °F to 158 °F (-40 ℃ to +70 ℃), 7 cycles, total 48 hrs |
| Temperature Cycle Test | – 40 °F to 158 °F (-40 ℃ to +70 ℃), 7 times cycle time testing, 48 hrs total |
| Operating Temperature | – 4 °F to 185 °F (-20 ℃ to +85 ℃) |
| Storage Temperature | -40 °F to 185 °F (-40 ℃ to +85 ℃) |
| Dimension | 3.4 in X 2.2 in X 0.1 in (88 mm X 56 mm X 4 mm) |
| Weight | 0.9 oz (27 g) |
