Description
Overview
Amuse Tech Solutions RFID Scanner Rugged Industrial Tablet Android 9.0 NFC Handheld RFID Reader is with abundant functions, is an Android 9.0 rugged tablet. With its powerful Qualcomm CPU, 8 in (20.32 cm) high-definition screen, 8000 mAh battery and comprehensive data capture options like UHF RFID, barcode scanning, HF RFID or NFC, Iris and fingerprint recognition, etc., you can find this easy-to-deploy device a valuable helper to increase productivity in retail, logistics, warehousing, identity verification, meter reading, etc.
Technical Specifications
| UHF Engine | CM2000-1 module based on Impinj Indy R2000 |
| UHF Frequency | 865 MHz to 868 MHz or 920 MHz to 925 MHz or 902 MHz to 928 MHz |
| UHF Protocol | EPC C1 GEN2 or ISO18000-6C |
| UHF Antenna | Circular polarization (default UHF, 3 dBi; UHF with pistol grip, 4 dBi) |
| Power | 1 W (30 dBm, +5 dBm to +30 dBm adjustable) |
| Reading and Writing Range | 82.02 ft (> 25 m) (indoors); 49.21 ft (> 15 m) (open outdoors, Impinj MR6 tag); |
| Reading Rate | > 200 tags per s (circular polarization) |
| NFC|HF Frequency | 13.56 MHz |
| NFC|HF Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| NFC|HF Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
| NFC|HF Reading distance | 0.79 in to 1.57 in (20 mm to 40 mm) |
| CPU | Qualcomm 1.8 GHz Octa-core |
| RAM+ROM | 2 GB + 16 GB or 3 GB + 32 GB |
| Octa-core CPU | Cortex-A53 Octa-core 2.5 GHz |
| Octa-core RAM+ROM | 2 GB + 16 GB or 3 GB + 32 GB |
| Octa-core Expansion | Supports up to 128 GB Mirco SD card |
| Operating System | Android 9.0 |
| WLAN | IEEE802.11 a/b/g/n, 2.4G or 5G dual-band, internal antenna |
| WWAN (Europe, Asia) | 2G: B3/B5/B8 3G: CDMA EVDO: BC0; TD-SCDMA: B34/B39; WCDMA: B1/B5/B8 4G: TDD-LTE: B38/B39/B40/B41; FDD-LTE: B1/B3/B5/B7/B8/B20 |
| WWAN (America) | 3G: B2/B4/B5 4G: B2/B4/B5/B7/B12/B13/B17/B28b |
| Bluetooth | Bluetooth 4.2/4.1 + HS/4.0/3.0 + HS/2.1 + EDR |
| GNSS | GPS or AGPS, GLONASS, BeiDou, internal antenna |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Power | Li-ion, rechargeable, 8000 mAh Standby: over 500 hrs Continuous use: over 10 hrs (depending on user environment) Charging time: 5 hrs to 7 hrs (with standard adaptor and USB cable) |
| Expansion Slot | 1 slot for SIM card, 1 slot for SIM or TF card |
| Interfaces | USB3.0 Type-C, OTG |
| Audio | Speaker and Microphones |
| Sensors | Gravity sensor, light sensor, proximity sensor |
| Display | 8 in (20.32 cm) IPS LTPS 1920 x 1200 or IPS LTPS 1280 x 800 |
| Dimensions | 9.87 in x 5.98 in x 0.59 in (250.8 mm x 152.0 mm x 15.0 mm) (for standard version) |
| Weight | 24.69 oz (700 g) (for standard version) |
