Description
Technical Specifications
| Frequency Range | 920 MHz to 925MHz |
| Gain | 8±1 dBi |
| Horizontal Beamwidth | 65 ± 5º |
| Vertical Beamwidth | 65 ± 5º |
| FB Ratio | ≥20 dB |
| Axial Ratio | 3±1 dB |
| V.S.W.R. | ≤1.8 |
| Impedance | 50 Ω |
| Polarization | Circular Polarization |
| Max. Power | 100 W |
| Connector | N straight male |
| Lightning Protection | DC grounding |
| Rated Wind Velocity | 36.9 ms |
| Operational Humidity | <95 % |
| Operating Temperature | – 40 ºF to 131 ºF (-40 ºC to 55 ºC) |
| Radome Material | ABS (white) |
| Reflector Material | AI |
| Dimension | 10.12 in x 10.12 in x 1.46 in (257 mm x257 mm x 37 mm) |
| Weight | 1.65 lb (0.75 kg) |
