Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol Supported | ISO/IEC 18000-6C EPC Class1 Gen2 |
| Chip | Alien HEC or H9 or H3 or H10 |
| Format Available | Dry Inlay or Wet Inlay or Label |
| Reading Range | Up to 39.37 ft (12 m) |
| Substrate | PET |
| Surface Material | Coated Paper or PET or PP |
| EPC | 128 Bits or 96 Bits or 96 Bits or 96 Bits |
| User Memory | 128 Bits or 688 Bits or 512 Bits or 32 Bits |
| Operating Mode | Passive |
| Write Cycles | 100000 times |
| ESD-HBM/CDM | 2000 V |
| Customized Support | Encoding, printing, etc. |
| Temperature | Operation -40 ºF to +158 ºF (-40 ºC to +70 ºC) Storage -4 ºF to +122 ºF (-20 ºC to +50 ºC) |
| Humidity | 20 % RH to 90 % RH |
| Antenna Size | 2.75 in x 0.67 in (70 mm x 17 mm) |
| Die cutter Size | 2.91 in x 0.94 in (74 mm x 24 mm) 2.83 in x 0.79 in (72 mm x 20 mm) or customized |
